Flyweight pattern

By implementing common game programming design patterns in your Unity project, you can efficiently build and maintain a clean, organized, and readable codebase. Design patterns not only reduce refactoring and the time spent testing, but they also speed up onboarding and development processes, contributing to a solid foundation that can be used to grow your game, development team, and business.

Think of design patterns not as finished solutions you can copy and paste into your code, but as extra tools that can help you build larger, scalable applications when used correctly.

This tutorial explains the flyweight pattern and how you can use it to reduce the amount of duplicated data in your game, thus ensuring it runs smoothly at runtime.

Languages available:

1. Overview

This tutorial explains the flyweight programming pattern and how you can use it in your Unity projects. Make sure to download the Level up your code with design patterns and SOLID sample project from the Unity Asset Store to follow along with the examples in this tutorial.

2. Introduction to the flyweight pattern

Large game worlds will often contain scenes populated with numerous GameObjects and components. If similar GameObjects carry the same data fields, this can result in significant duplication of data, leading to increased memory usage. Let’s consider a forest scene as an example, where each tree GameObject stores its own configuration data.

A tree in our game scene might store the following:

  • Complex data structures for defining the tree. If you were generating the tree procedurally, this could include arrays or lists of floats, colors, and Vector3 values.
  • Animation curves for defining how the tree sways in the wind.
  • Custom class instances that define other physical characteristics or gameplay metadata.

Though each individual field may be relatively small, remember that duplicating the GameObject also copies its various components and their stored data fields. If a field is a value type (for example, a struct, primitive type, or array), each duplicated GameObject will have its own copy of the data. Populate your game world forest with trees, and this redundancy quickly adds up.

The flyweight pattern is an optimization pattern that can reduce the amount of duplicated data in your game by centralizing shared data. Thus, it allows individual objects to reference this shared data instead of storing their own copies.

If you're accustomed to the prefab workflow in Unity, then you're already familiar with this idea. We can share as much data as possible between similar GameObjects, reducing the overall memory footprint.

3. An unoptimized example before refactoring

Consider a strategy game teeming with gameplay units. Each might carry attributes such as health, attack, defense, and movement. To identify each unit, you also might want to tag them with a team label and icon.

Thus, an unoptimized gameplay unit might have a class like this:

public class UnrefactoredUnitInstance : MonoBehaviour
{
    public string factionName;
    public Sprite factionIcon;
    public int baseHealth;
    public int baseAttack;
    public int baseDefense;
    public int baseMovement;

    // Unique state for this unit instance
    public int health;
    public int attack;
    public int defense;
    public int movement;
    public Vector3 position;


    private void Start()
    {
        RefreshUnitStats();
    }

    private void RefreshUnitStats()
    {
        health = baseHealth;
        attack = baseAttack;
        defense = baseDefense;
        movement = baseMovement;
        // ... update other unit components based on faction data
    }

    public void SetFactionData(string factionName, Sprite factionIcon, int baseHealth, int baseAttack, int baseDefense, int baseMovement)
    {
        this.factionName = factionName;
        this.factionIcon = factionIcon;
        this.baseHealth = baseHealth;
        this.baseAttack = baseAttack;
        this.baseDefense = baseDefense;
        this.baseMovement = baseMovement;

        RefreshUnitStats();
    }
}

In addition to its own stats, a unit carries an additional payload of data that should ideally remain constant across a given faction or team. When creating a new unit instance with the SetFactionData method, you pass all the common faction data – and store a copy of it. The more units you add, the more redundant data you're duplicating and storing.

This doesn't just use up more memory – it also makes it harder to keep everything updated and consistent across your game. Manually syncing data across many GameObjects is error prone and can lead to inconsistencies.

With a handful of GameObjects, it's not a problem. But with a large number of units from the same faction, the increased memory usage might start to be noticeable – or at least difficult to manage.

4. Implementing the flyweight pattern

A simple solution is to store the shared data in a central repository, or flyweight GameObject.

A ScriptableObject works well for this purpose since it’s ideal for storing data that doesn’t need to change at runtime (for example, settings, configuration data, etc.)

Refactoring the shared data into a separate class can reduce redundancy, like so:

// Flyweight object (ScriptableObject)
[CreateAssetMenu]
public class FactionData : ScriptableObject
{
    public string factionName;
    public Sprite factionIcon;
    public int baseHealth;
    public int baseAttack;
    public int baseDefense;
    public int baseMovement;
}

// Context object
public class UnitInstance : MonoBehaviour
{
    public FactionData factionData;

    private void Start()
    {
        RefreshUnitStats();
    }

    private void RefreshUnitStats()
    {
        health = factionData.baseHealth;
        attack = factionData.baseAttack;
        defense = factionData.baseDefense;
        movement = factionData.baseMovement;

        // ...Update other unit components based on faction data
    }

    // Unique state for this unit instance
    public int health;
    public int attack;
    public int defense;
    public int movement;

    public Vector3 position;

    // ... Add other unique states here
}

Using the flyweight pattern, the FactionData class is a ScriptableObject that represents the shared faction data. It contains fields for the faction name, icon, and base unit stats.

The UnitInstance class is the Context GameObject that holds a reference to the FactionData ScriptableObject. It refreshes its stats based on the shared faction data. By separating shared and unique data, you reduce memory usage and potential inconsistencies across your GameObjects.

5. Optimize memory usage with the flyweight pattern

The following example demonstrates the flyweight pattern by optimizing memory usage for a fleet of spaceships.

The core principle of the flyweight pattern is that it distinguishes between intrinsic (shared) and extrinsic (unique) state data. Intrinsic data is immutable and shared across instances, reducing memory usage. Extrinsic data varies between instances and is stored individually.

In this example, ShipData is a ScriptableObject that contains intrinsic, shared data for all ships, such as unit name, speed, attack power, and defense. All ships reference the same data set for these properties, minimizing the memory footprint.

[CreateAssetMenu(fileName = "ShipData", menuName = "Flyweight/ShipData", order = 1)]
public class ShipData : ScriptableObject
{
    public string UnitName;
    public string Description;
    public float Speed;
    public int AttackPower;
    public int Defense;
}

With the above script, you’re able to create the ScriptableObject instance from the context menu defined in the CreateAssetMenu attribute. We already created one that you can find in the LevelUpYourCode > _DesignPatterns > 9_Flyweight > ScriptableObjects folder.

A Ship class can represent individual ships in the fleet. Each ship instance holds a reference to the shared ShipData and, in turn, manages its own unique state, such as health.

public class Ship : MonoBehaviour
{
    [SerializeField] private ShipData m_SharedData;
    [SerializeField] private float m_Health;

    public void Initialize(ShipData data, float health)
    {
        m_SharedData = data;
        m_Health = health;
    }

    public void DisplayShipInfo()
    {
        Debug.Log($"Name: {sharedData.UnitName}, Health: {m_Health}");
    }
}

The ShipFactory is responsible for generating the fleet of ships. It initializes each ship using a prefab GameObject and the shared ShipData.

public class ShipFactory : MonoBehaviour
{
    [SerializeField] private Ship shipPrefab;
    [SerializeField] private ShipData sharedShipData;
    [SerializeField] private float spacing = 1.0f;

    void Start()
    {
        GenerateShips(10, 10);
    }

    public void GenerateShips(int rows, int columns)
    {
        for (int i = 0; i < rows; i++)
        {
            for (int j = 0; j < columns; j++)
            {
                Vector3 position = new Vector3(i * spacing, 0, j * spacing);
                Ship newShip = Instantiate(shipPrefab, position, Quaternion.identity, transform);
                newShip.Initialize(sharedShipData, 100); // Assuming 100 is the starting health
                newShip.name = $"Ship_{i * columns + j}";
            }
        }
    }
}

By centralizing shared data in a ScriptableObject, you can reduce the memory footprint across numerous ship instances. Meanwhile, unique data such as health is still managed individually by each ship instance.

Though this isn’t much memory saving per GameObject, the efficiencies become more noticeable the more ships you add to the scene. Large numbers of similar objects make the best use of the flyweight pattern.

Add the Memory Profiler package from the Package Manager to get better insight into the memory savings. In the Memory Profiler window (Window > Analysis > Memory Profiler), search through the managed GameObjects to determine the allocated size. Compare before implementing the pattern versus applying the Flyweight GameObject.

While the sample scene only showcases a few shared fields, the flyweight pattern's benefits can become substantial in large-scale projects like RPGs or strategy games with numerous onscreen units.

Use the flyweight pattern to save resources whenever you have a large number of objects that share common properties in their base classes.

6. Pros and cons of using the flyweight pattern

The flyweight pattern excels in scenarios where numerous GameObjects share a common state. This is particularly useful on resource-constrained platforms, such as mobile devices, where reducing memory consumption can improve performance. Applications that require instantiating a large number of GameObjects can use the flyweight pattern to their advantage to scale more effectively.

However, the flyweight pattern incurs additional overhead and complexity. In addition to managing the individual GameObjects in your scene, you'll also need to manage their shared state. The benefit from the flyweight pattern only becomes tangible when there are a sufficient number of units to justify the additional overhead.

Also, because you're forcing units to share the same basic data, that limits their flexibility. You'll need to override the shared data to make each unit unique, akin to the prefab workflow but applied to specific data sets.

7. More use case examples

Though much of what the flyweight pattern provides can also be achieved using prefabs, it can be a good choice for the following types of cases:

  • Crowd simulations: Building a sports sim with some background crowds? Use the pattern to share models, animations, and textures to build large, dynamic crowds.
  • Character/weapon skins and customization: Many games often allow players to customize their weapons or gear with skins and attachments. The base properties of these items can be shared with Flyweights, with only the customizations stored individually.
  • Level art: When designing a forest, take all of the universal properties of a tree and store them in the base Tree class. Then, you don’t need to repeat them in the subclasses (for example, PineTree, MapleTree, and so on).

Note that in scenarios where your game features thousands of GameObjects with shared data (such as a swarm of projectiles in an intense shooter or armies of units in an action strategy game), consider using Unity’s Data-Oriented Technology Stack (DOTS) instead. DOTS can offer superior performance optimization through its focus on multithreading and reducing data dependencies. Check out the DOTS e-book for advanced Unity developers for an in-depth look at each of the packages and technologies in the stack and their related concepts.

As with any design pattern, evaluate the specific needs of your project before implementing it. Then, decide as a team which pattern will give the best benefit.

8. More resources

If you want to learn more about design programming patterns and how you can use them in your Unity projects, make sure to read the updated guide Level up your code with design patterns and SOLID and follow along with the Level up your code with design patterns and SOLID sample project on the Unity Asset Store.

Additionally, watch the Game Programming Patterns Tutorials video tutorials playlist where you can see a lot of these programming patterns in action:

You can find all advanced Unity technical e-books and articles on the best practices hub. The e-books are also available on the Advanced best practices page in the documentation.
