Inheritance

Understand high-level programming concepts (such as inheritance, encapsulation, data abstraction, and polymorphism) and how they are implemented.

Level 2 Programming theory

Joy Horvath

Instructional Designer

U_Intermediate_6_Inheritance.mp4

How to use inheritance to reuse code and build a strong relationship between related classes.

Games

Explain how abstraction is used to expose only necessary script components

Explain how inheritance is used to share functionality between a parent and child class

Define the relationship between a parent and child class, including what a child class can and cannot do with respect to its parent class

Recognize opportunities where inheritance could be used to simplify code

Describe how polymorphism can be applied at compile time (method overloads) and run time (method overrides)

Explain how polymorphism is used to modify parent class functionality in a child class

Explain how encapsulation is used to write code that can only be used as intended by the programmer

Recommend a high-level system architecture for a given project

Simplify code and make it reusable by correctly implementing the principles of inheritance and polymorphism

Intermediate Scripting

Game Design Curricular Framework Resources

using UnityEngine;
using System.Collections;

//This is the base class which is
//also known as the Parent class.
public class Fruit
{
    public string color;

    //This is the first constructor for the Fruit class
    //and is not inherited by any derived classes.
    public Fruit()
    {
        color = "orange";
        Debug.Log("1st Fruit Constructor Called");
    }

    //This is the second constructor for the Fruit class
    //and is not inherited by any derived classes.
    public Fruit(string newColor)
    {
        color = newColor;
        Debug.Log("2nd Fruit Constructor Called");
    }

    public void Chop()
    {
        Debug.Log("The " + color + " fruit has been chopped.");
    }

    public void SayHello()
    {
        Debug.Log("Hello, I am a fruit.");
    }
}


using UnityEngine;
using System.Collections;

//This is the derived class whis is
//also know as the Child class.
public class Apple : Fruit
{
    //This is the first constructor for the Apple class.
    //It calls the parent constructor immediately, even
    //before it runs.
    public Apple()
    {
        //Notice how Apple has access to the public variable
        //color, which is a part of the parent Fruit class.
        color = "red";
        Debug.Log("1st Apple Constructor Called");
    }

    //This is the second constructor for the Apple class.
    //It specifies which parent constructor will be called
    //using the "base" keyword.
    public Apple(string newColor) : base(newColor)
    {
        //Notice how this constructor doesn't set the color
        //since the base constructor sets the color that
        //is passed as an argument.
        Debug.Log("2nd Apple Constructor Called");
    }
}


using UnityEngine;
using System.Collections;

public class FruitSalad : MonoBehaviour
{
    void Start ()
    {
        //Let's illustrate inheritance with the
        //default constructors.
        Debug.Log("Creating the fruit");
        Fruit myFruit = new Fruit();
        Debug.Log("Creating the apple");
        Apple myApple = new Apple();

        //Call the methods of the Fruit class.
        myFruit.SayHello();
        myFruit.Chop();

        //Call the methods of the Apple class.
        //Notice how class Apple has access to all
        //of the public methods of class Fruit.
        myApple.SayHello();
        myApple.Chop();

        //Now let's illustrate inheritance with the
        //constructors that read in a string.
        Debug.Log("Creating the fruit");
        myFruit = new Fruit("yellow");
        Debug.Log("Creating the apple");
        myApple = new Apple("green");

        //Call the methods of the Fruit class.
        myFruit.SayHello();
        myFruit.Chop();

        //Call the methods of the Apple class.
        //Notice how class Apple has access to all
        //of the public methods of class Fruit.
        myApple.SayHello();
        myApple.Chop();
    }
}


Inheritance

1. Inheritance

Complete this tutorial
