Quiz Game - Intro and Setup [1/8] Live 2016/11/14

Quiz Game - Data Classes  [2/8] Live 2016/11/14

Quiz Game - Menu Screen  [3/8] 2016/11/14

Quiz Game - Game UI  [4/8] Live 2016/11/14

Quiz Game - Answer Button  [5/8] Live 2016/11/14

Quiz Game - Displaying Questions  [6/8] Live 2016/11/14

Quiz Game - Click To Answer  [7/8] Live 2016/11/14

Quiz Game - Ending The Game and Q&A  [8/8] Live  2016/11/14

In this live training session we will look at creating a multiple choice quiz game. We will create the core game loop - timer, score, win and lose states. We will also show code architecture best practices - keeping data and logic separate, and how to structure a game in a way that makes it easy to maintain and extend. We will look at some of the ways we can extend this in session two.



using UnityEngine;
using System.Collections;

[System.Serializable]
public class AnswerData
{
    public string answerText;
    public bool isCorrect;

}


using UnityEngine;
using System.Collections;

[System.Serializable]
public class QuestionData
{
    public string questionText;
    public AnswerData[] answers;
}

using UnityEngine;
using System.Collections;

[System.Serializable]
public class RoundData
{
    public string name;
    public int timeLimitInSeconds;
    public int pointsAddedForCorrectAnswer;
    public QuestionData[] questions;

}

using UnityEngine;
using System.Collections;
using UnityEngine.SceneManagement;

public class DataController : MonoBehaviour
{
    public RoundData[] allRoundData;


    // Use this for initialization
    void Start ()
    {
        DontDestroyOnLoad (gameObject);

        SceneManager.LoadScene ("MenuScreen");
    }

    public RoundData GetCurrentRoundData()
    {
        return allRoundData [0];
    }

    // Update is called once per frame
    void Update () {

    }
}

using UnityEngine;
using System.Collections;
using UnityEngine.SceneManagement;

public class MenuScreenController : MonoBehaviour {

    public void StartGame()
    {
        SceneManager.LoadScene("Game");
    }
}

using UnityEngine;
using System.Collections.Generic;

// A very simple object pooling class
public class SimpleObjectPool : MonoBehaviour
{
    // the prefab that this object pool returns instances of
    public GameObject prefab;
    // collection of currently inactive instances of the prefab
    private Stack<GameObject> inactiveInstances = new Stack<GameObject>();

    // Returns an instance of the prefab
    public GameObject GetObject()
    {
        GameObject spawnedGameObject;

        // if there is an inactive instance of the prefab ready to return, return that
        if (inactiveInstances.Count > 0)
        {
            // remove the instance from teh collection of inactive instances
            spawnedGameObject = inactiveInstances.Pop();
        }
        // otherwise, create a new instance
        else
        {
            spawnedGameObject = (GameObject)GameObject.Instantiate(prefab);

            // add the PooledObject component to the prefab so we know it came from this pool
            PooledObject pooledObject = spawnedGameObject.AddComponent<PooledObject>();
            pooledObject.pool = this;
        }

        // enable the instance
        spawnedGameObject.SetActive(true);

        // return a reference to the instance
        return spawnedGameObject;
    }

    // Return an instance of the prefab to the pool
    public void ReturnObject(GameObject toReturn)
    {
        PooledObject pooledObject = toReturn.GetComponent<PooledObject>();

        // if the instance came from this pool, return it to the pool
        if(pooledObject != null && pooledObject.pool == this)
        {
            // disable the instance
            toReturn.SetActive(false);

            // add the instance to the collection of inactive instances
            inactiveInstances.Push(toReturn);
        }
        // otherwise, just destroy it
        else
        {
            Debug.LogWarning(toReturn.name + " was returned to a pool it wasn't spawned from! Destroying.");
            Destroy(toReturn);
        }
    }
}

// a component that simply identifies the pool that a GameObject came from
public class PooledObject : MonoBehaviour
{
    public SimpleObjectPool pool;
}

using UnityEngine;
using System.Collections;
using UnityEngine.UI;

public class AnswerButton : MonoBehaviour {

    public Text answerText;

    private AnswerData answerData;
    private GameController gameController;

    // Use this for initialization
    void Start ()
    {
        gameController = FindObjectOfType<GameController> ();
    }

    public void Setup(AnswerData data)
    {
        answerData = data;
        answerText.text = answerData.answerText;
    }


    public void HandleClick()
    {
        gameController.AnswerButtonClicked (answerData.isCorrect);
    }
}

using UnityEngine;
using System.Collections;
using UnityEngine.UI;
using UnityEngine.SceneManagement;
using System.Collections.Generic;

public class GameController : MonoBehaviour {


    public Text questionDisplayText;
    public Text scoreDisplayText;
    public Text timeRemainingDisplayText;
    public SimpleObjectPool answerButtonObjectPool;
    public Transform answerButtonParent;
    public GameObject questionDisplay;
    public GameObject roundEndDisplay;

    private DataController dataController;
    private RoundData currentRoundData;
    private QuestionData[] questionPool;

    private bool isRoundActive;
    private float timeRemaining;
    private int questionIndex;
    private int playerScore;
    private List<GameObject> answerButtonGameObjects = new List<GameObject>();

    // Use this for initialization
    void Start ()
    {
        dataController = FindObjectOfType<DataController> ();
        currentRoundData = dataController.GetCurrentRoundData ();
        questionPool = currentRoundData.questions;
        timeRemaining = currentRoundData.timeLimitInSeconds;
        UpdateTimeRemainingDisplay();

        playerScore = 0;
        questionIndex = 0;

        ShowQuestion ();
        isRoundActive = true;

    }

    private void ShowQuestion()
    {
        RemoveAnswerButtons ();
        QuestionData questionData = questionPool [questionIndex];
        questionDisplayText.text = questionData.questionText;

        for (int i = 0; i < questionData.answers.Length; i++)
        {
            GameObject answerButtonGameObject = answerButtonObjectPool.GetObject();
            answerButtonGameObjects.Add(answerButtonGameObject);
            answerButtonGameObject.transform.SetParent(answerButtonParent);

            AnswerButton answerButton = answerButtonGameObject.GetComponent<AnswerButton>();
            answerButton.Setup(questionData.answers[i]);
        }
    }

    private void RemoveAnswerButtons()
    {
        while (answerButtonGameObjects.Count > 0)
        {
            answerButtonObjectPool.ReturnObject(answerButtonGameObjects[0]);
            answerButtonGameObjects.RemoveAt(0);
        }
    }

    public void AnswerButtonClicked(bool isCorrect)
    {
        if (isCorrect)
        {
            playerScore += currentRoundData.pointsAddedForCorrectAnswer;
            scoreDisplayText.text = "Score: " + playerScore.ToString();
        }

        if (questionPool.Length > questionIndex + 1) {
            questionIndex++;
            ShowQuestion ();
        } else
        {
            EndRound();
        }

    }

    public void EndRound()
    {
        isRoundActive = false;

        questionDisplay.SetActive (false);
        roundEndDisplay.SetActive (true);
    }

    public void ReturnToMenu()
    {
        SceneManager.LoadScene ("MenuScreen");
    }

    private void UpdateTimeRemainingDisplay()
    {
        timeRemainingDisplayText.text = "Time: " + Mathf.Round (timeRemaining).ToString ();
    }

    // Update is called once per frame
    void Update ()
    {
        if (isRoundActive)
        {
            timeRemaining -= Time.deltaTime;
            UpdateTimeRemainingDisplay();

            if (timeRemaining <= 0f)
            {
                EndRound();
            }

        }
    }
}

In this live training session we will look at creating a multiple choice quiz game. We will create the core game loop - timer, score, win and lose states. We will also show code architecture best practices - keeping data and logic separate, and how to structure a game in a way that makes it easy to maintain and extend. We will look at some of the ways we can extend this in session two.

Recorded Video Session: Quiz Game 1

1. Intro and Setup

2. Data Classes

3. Menu Screen

4. Game UI

5. Answer Button

6. Displaying Questions

7. Click To Answer

8. Ending The Game and Q&A
